直線篩

產品描述：

直線篩

按需定制

多種規格

質量保障

終生維修

服務咨詢熱線： 18603807035

立即咨詢

產品介紹合作案例產品優勢更多產品

產品介紹

product

一、概述Introduction

輕型直線振動篩是利用兩臺振動電機為激震源，反向轉動時產生的激振力，通過傳振體傳遞到輕型直線振動篩整個篩面上，從而使篩面上的物料向出料口方向跳躍運動。小于篩孔的物料通過篩網落到下層，經連續跳躍后從出料口流出，卡在篩網上的物料由橡膠球彈出，由于篩分過程合理，可同時取得幾種不同規格的物料。可配單篩或多篩，實現分級，去除雜質，除塵，檢測，洗選，脫水等。

The light linear vibrating screen uses two vibrating motors as the shock source, and the exciting force generated in the reverse rotation is transmitted to the entire screen surface of the light linear vibrating screen through the vibration transmitting body, so that the material on the screen surface is directed to the discharging port, direction jump movement. The material smaller than the sieve hole falls to the lower layer through the screen, and flows out from the discharge port after continuous jumping. The material stuck on the screen is ejected by the rubber ball. Since the screening process is reasonable, several materials of different specifications can be obtained at the same time. Can be equipped with single or multiple screens to achieve classification, impurity removal, dust removal, detection, washing, dehydration, etc.

二、應用范圍Applied field

DZSF系列輕型直線振動篩主要適用于，塊狀、顆粒狀、粉狀物料的篩分。如磨料、建材、醫藥、化工、冶金、樹脂粉、陶瓷原料等，可根據客戶需要，現場尺寸要求，進行設計制作。

DZSF series light linear vibrating screen is mainly suitable for screening of block, granular and powder materials. Such as abrasives, building materials, medicine, chemicals, metallurgy, resin powder, ceramic raw materials, etc., according to customer needs, on-site size requirements, design and production.

三、技術參數Technical parameters

輕型直線振動篩	篩面尺寸	篩面層數	網孔尺寸（目/in）	處理量（t/h）	振次Min	雙振幅	電機功率	振動方向角（°）	外型尺寸 (長×寬×高) （mm）
DZSF520	500×2000	1	2~200	0.05~5	960	3~6	2×0.37	45~60	2075×806×990
2DZSF520		2		0.05~5	960	3~6	2×0.37	458~60	2135×806×1050
3DZSF520		3		0.03~5	960	3~6	2×0.37	45	2195×806×1110
DZSF525	500×2500	1		0.06~8	960	3~6	2×0.37	45~60	2575×806×990
2DZSF525		2		0.06~8	960	3~6	2×0.37	45	2635×806×1050
3DZSF525		3		0.06~8	960	3~6	2×0.75	45~60	2695×806×1110
4DZSF525		4		0.1~15	960	3~6	2×0.37	45	2755×806×1170
5DZSF525		5		0.08~15	960	3~6	2×0.37	45	2815×806×1230
6DZSF525		6		0.07~15	960	3~6	2×0.75	45~60	2875×806×1290
DZSF1020	1000×2000	1		0.12~20	960	3~6	2×0.75	45~60	2075×1278×1120
2DZSF1020		2		0.11~20	960	3~6	2×0.75	45~60	2135×1278×1180
3DZSF1020		3		0.1~2	960	3~6	2×0.75	45~60	2195×1278×1240
4DZSF1020		4		0.07~15	960	3~6	2×0.75	45~60	2255×1278×1300
5DZSF1020		5		0.07~15	960	3~6	2×1.5	45~60	2315×1278×1360
6DZSF1020		6		0.07~15	960	3~6	2×1.5	45~60	2375×1278×1420
DZSF1025	1000×2500	1		0.1~15	960	3~6	2×0.37	45	2575×1278×1120
2DZSF1025		2		0.08~15	960	3~6	2×0.37	45	2635×1278×1180
3DZSF1025		3		0.07~15	960	3~6	2×0.75	45~60	2695×1278×1240
DZSF830	800×3000	1		0.1~20	960	3~6	2×0.75	45~60	3080×1098×1120
2DZSF830		2		0.1~20	960	3~6	2×0.75	45~60	3140×1098×1180
3DZSF830		3		0.1~20	960	3~6	2×1.5	45~60	3200×1098×1240
DZSF1030	1000×3000	1		0.1~20	960	3~6	2×0.75	45~60	3080×1298×1120
2DZSF1030		2		0.1~20	960	3~6	2×1.5	45~60	3080×1298×1120
3DZSF1030		3		0.1~20	960	3~6	2×1.5	45~60	3080×1298×1120
DZSF1224	1200×2400	1		0.1~23	960	3~6	2×0.75	45~60	2480×1520×1100
2DZSF1224		2		0.1~23	960	3~6	2×0.75	45~60	2540×1520×1160
3DZSF1224		3		0.1~23	960	3~6	2×1.5	45~60	2600×1520×1220
